Interface: PUCO Commercial Vehicle Information System - Freight Truck Vehicle

PUCO Commercial Vehicle Information System to Freight Truck Vehicle Interface Diagram

Architecture Flow Definitions

electronic lock data  (Planned )  Applicable ITS Standards

Notification to roadside (via transponder) of the presence and status of electronic cargo locks.

electronic lock data request  (Planned )  Applicable ITS Standards

Request from roadside for data regarding presence and status of electronic cargo locks.

electronic screening request  (Planned )  Applicable ITS Standards

Request for identification data to support electronic screening.

on-board safety data  (Planned )  Applicable ITS Standards

Safety data measured by on-board sensors. Includes information about the vehicle, vehicle components, cargo, and driver. The query flow is not explicitly shown.

on-board safety request*  (Planned )

Request for on-board vehicle safety data by the roadside equipment. The asterisk (*) indicates that this flow has been discontinued and is no longer included in the National ITS Architecture.

pass/pull-in  (Planned )  Applicable ITS Standards

Command to commercial vehicle to pull into or bypass inspection station.

request tag data  (Planned )  Applicable ITS Standards

Request for tag information including credit identity, stored value card cash, etc.

safety inspection record  (Planned )  Applicable ITS Standards

Record containing results of commercial vehicle safety inspection.

safety inspection request  (Planned )  Applicable ITS Standards

Request for safety inspection record.

screening event record  (Planned )  Applicable ITS Standards

Results of CVO electronic screening activity.

tag data  (Planned )  Applicable ITS Standards

Unique tag ID and related vehicle information.
