Interface: ODOT ATMS - ODOT OHGO

ODOT ATMS to ODOT OHGO Interface Diagram

Architecture Flow Definitions

incident information for public  (Planned )  Applicable ITS Standards

Report of current desensitized incident information prepared for public dissemination.

road network conditions  (Planned )  Applicable ITS Standards

Current and forecasted traffic information, road and weather conditions, and other road network status. Either raw data, processed data, or some combination of both may be provided by this flow. Information on diversions and alternate routes, closures, and special traffic restrictions (lane/shoulder use, weight restrictions, width restrictions, HOV requirements) in effect is included.

road network environmental situation data  (Planned )  Applicable ITS Standards

Aggregated environmental situation data collected from vehicles and other sources for the road network. Aggregated information would include measured air temperature, exterior light status, wiper status, sun sensor status, rain sensor status, traction control status, ALB status, and other collected vehicle system status and sensor information for the region.

road network traffic situation data  (Existing)  Applicable ITS Standards

Aggregated route usage, travel times, and other aggregated data collected from probe vehicles that can be used to estimate current traffic conditions.

traffic control information  (Planned )  Applicable ITS Standards

Represents the flow of traffic control and status information from a TMC to a third party TIC. This is reporting only, not actual control.

traffic images  (Planned )  Applicable ITS Standards

High fidelity, real–time traffic images suitable for surveillance monitoring by the operator or for use in machine vision applications. This flow includes the images and meta data that describes the images.
