Interface: Private Rail Wayside Equipment - ODOT Connected Vehicle Roadside Equipment

Private Rail Wayside Equipment to ODOT Connected Vehicle Roadside Equipment Interface Diagram

Architecture Flow Definitions

arriving train information  (Planned )  Applicable ITS Standards

Information for a train approaching a highway–rail intersection that may include direction and allow calculation of approximate arrival time and closure duration.

rail crossing blockage notification  (Planned )  Applicable ITS Standards

Notification that a highway–rail intersection is obstructed and supporting information.

rail crossing operational status  (Planned )  Applicable ITS Standards

Status of the highway–rail grade crossing equipment including both the current state or mode of operation and the current equipment condition.

track status  (Planned )  Applicable ITS Standards

Current status of the wayside equipment and notification of an arriving train.
